Consew Model 733R-6



Applications

•  For stitching extra heavy-weight materials.  Can sew up to size Tex 556 cord (thread.)

• Designed for such operations and products as extra heavy duty harnesses and slings (can sew up to 18,000 lb strength webbing,) safety and logging belts, cargo slings, tents, sails,  tarpaulins and covers, fabric structures, construction barriers, buffing wheels, parachutes, balloons, industrial bags, boot stitching, book binding

Features

• Syncronized upper and lower feeding mechanism assures uniform stitching

• Alternating presser feet
• Steel insert for take-up hinge

• Reverse stitching - hand or foot operated

• Stitch regulator - hand or foot operated

• Presser foot lift - hand or foot operated

• 1-11/32 inch presser foot lift (Can sew up to 6 plies of webbing)

• Two row feeder

• Two stitches to the inch

• Stitches per minute - 550

• Extra large vertical and horizontal workspace,  oscillating shuttle, hook and bobbin

• Belt guard

• Design to sew Cordura and Dyneema material, up to 18,000 lb strength webbing and can use up to size Tex 556 cord (thread.)

733R-6 IMPROVEMENTS

• Improvements allowing for use of thicker thread and heavier materials:
  • 1-3/8” (35mm) needle clearance
  • More leverage on presser foot lifter  for easier lifting
  • Now comes with bobbin spindle adapter  already installed for pre-wound bobbins
  Along with modifications /improvements to
  • Needle Plate       • Center Foot       • Needle Bar Clamp       • Shuttle Driver
  • Stitch Regulator Limiting Pins and other modifications aimed at smoother running with heavier threads and materials.

ADDITIONAL INFORMATION

• 733R-5 Instruction Manual and Parts Book
• 733R-5 Instruction Manual
• Consew Sewing Machine 733R-5 Demo:  https://youtu.be/DVKT6g9xOhw
• 733R-6 Spec Sheet (PDF)
